FAMILY VT.DTT.21
TCT Brazed Cutter Head Set For Door — Extra Long Tenon
Use for
Extra-long-tenon door tooling for solid wood and panel material on spindle moulders.
Precision dimensionsExact SKU selectionQuote on request
6 available variants
Diameter (D)BoreWood ThickTeeth
Choose your dimensions.
Diameter × Bore × Wood Thickness × Teeth (mm)
6 variants shownView quote list (0) →
| Rakecraft SKU | Code no. | Diameter (D) | Bore | Wood Thick | Teeth | Quantity | Select |
|---|---|---|---|---|---|---|---|
| RC-P41-VTDTT21-VTDTT211069 | VT.DTT.21.1069 | 125/200 | 25.4/30 | 32-40 | 4/6 | ||
| RC-P41-VTDTT21-VTDTT211070 | VT.DTT.21.1070 | 125/200 | 25.4/30 | 32-40 | 4/6 | ||
| RC-P41-VTDTT21-VTDTT211071 | VT.DTT.21.1071 | 125/200 | 25.4/30 | 32-40 | 4/6 | ||
| RC-P41-VTDTT21-VTDTT211072 | VT.DTT.21.1072 | 125/200 | 25.4/30 | 32-40 | 4/6 | ||
| RC-P41-VTDTT21-VTDTT211073 | VT.DTT.21.1073 | 125/200 | 25.4/30 | 32-40 | 4/6 | ||
| RC-P41-VTDTT21-VTDTT211074 | VT.DTT.21.1074 | 125/200 | 25.4/30 | 32-40 | 4/6 |
Technical and selection notes
Extra-long-tenon tooling remains separate from the standard VT.DT.19 door family; compound values are preserved exactly.
Reference catalog: pages 38. View catalog ↗
